Unparalleled Dispensing Accuracy...

Precision. For positive displacement deposition of dots, beads or fills with unsurpassed accuracy and precision, nothing compares to the Champion 6809. Single shot deposits below 0.5 nanoliters. Accuracy is measured to 1.76% 3 sigma.

Versatility. From dots to lines, underfill and encapsulation, Digital Deposition and the Champion 6809 deliver the accuracy and repeatability demanded by today's exacting applications.

Options
Camera and Vision. A closed circuit camera with picture-in-picture display on the monitor, for easy programming and inspection. The Automatic Vision Correction System establishes the X, Y and Ø orientation of the part and compensates for stretch, skew and misalignment.

Height Sensing. Both contact probe and non-contact laser are available for height sensing and height mapping.

- X & Y Axes Linear Encoders
- Z Axes Rotary Encoder

- Powerful, easy-to-use Windows style Software

- LCD Display

- Rugged Construction and Quiet operation

- Small Footprint

- Full 1-year warranty

Optional Feature

- Auto vision alignment and dot verification

- Programmable lighting

- Auto height mapping

- Auto tip calibration

- CAD import with path optimization

- True Volume™ pump - dots to below 0.5 nanoliters (0.0000005µl)

- Contact or non-contact (Laser) height mapping

- Substrate, needle and material heaters

The CHAMPION 6809 is a servo driven, automatic dispensing system designed for precision processes. The system can be configured to match exacting application requirements from dots to under fill with a broad array of options.

Creative Automation Company's Digital Deposition process achieves the highest levels of accuracy, speed and repeatability available today. A single Creative Automation True Volume™ Pump is capable of firing up to 90,000 precision deposits per hour to form high definition dots, lines, fills and builds - precisely shaped by true piston positive displacement. Volumetric accuracy is ensured regardless of deposit size, viscosity or temperature.

Features
Powerful, easy-to-use proprietary software. The graphics user interface allows intuitive programming and control. The system includes a large, bright, high contrast color LCD display.
